817 E Mobile

Machine Type:

817 E Mobile

Specifically developed to meet the needs of the recycling and waste management industries, the SENNEBOGEN 817 E is a compact, agile and efficient solution for sorting and loading tasks. In addition to its many sophisticated features, it functions impressively in halls with low ceilings.

Conceived for recycling

  • Precise work thanks to boom damping as standard feature
  • Optionally available with protective ventilation system for adverse environmental conditions
  • Optional 75 kW electric motor, ideal for operation in halls

Environmentally friendly, economical, high-performance

  • Quick and agile sorting work
  • 97 kW diesel engine adjusted to the latest emission standards incl. diesel particulate filter
  • Emission-reduced, ECO mode, automatic idle/stop function
  • Maintenance-optimized, longitudinally installed engine

For demanding tasks

  • Various additional packages for added protection: Low temperature, dust protection, heat and lighting packages
  • Large four-point support base for stable work
  • Pipe burst protection on boom and stick

Quick and compact

  • Compact material handler for sorting work
  • Small front and rear end radius (1.96 meters) allows easy turning
  • Direct and rapid control over all work areas

Maximum work comfort

  • Multicab with panoramic view
  • Comfortable access from the ground
  • Ideal visibility thanks to a viewing height of 5.3 meters
  • Highly responsive joystick control

Flexible all-rounder

  • Versatile configuration thanks to variable boom lengths
  • Wide range of SENNEBOGEN attachments available:
    • Sorting grab
    • Orange peel grab
    • Clamshell grab
    • Magnet plate (9 kW magnetic generator optional)


Technical data:
Peso operativo
17,2 t
Massimo sbraccio
9 m
Motore diesel
97 kW
Motore elettrico
75 kW
